Nexus 1252 Substation 19″ Rack Mount Assembly

Nexus 1252 Substation 19″ Rack Mount Assembly

Contact us for more information on this product

View full details


EIG’s rack mount assembly offers the Nexus® 1252 advanced performance power meter and power quality recorder together with three LED displays in one mountable unit. The rack assembly accommodates the Nexus® 1252 power meter, any optional I/O modules, a Test switch and the three displays.

  • Enhanced Visibility and Ease of Use
  • Designed for Rack Installation

Enhanced Visibility and Ease of Use
Great for Field Personnel

  • Three bright-red, 0.56” lines of data in each LED display for easy viewing, with no scrolling.
  • Incorporates nine simultaneous lines for display in one mountable unit.
  • View relevant data easily from the preconfigured displays:
    • P40N+ – Master display providing either multifunction measurement or use as a volts master unit
    • P41N+ – Amperes slave display
    • P43N+ – Power slave display
  • Constructed for easy installation

Designed for Rack Installation

  • Built-in Test switch
  • Front panel serial port for easy downloads
  • Easy access to Com ports behind rack mount assembly
